The proposed system to produce solar thermochemical hydrogen (STCH), outlined in Solar Energy Journal, offers a new greenhouse gas (GHG) emissions-free process relying entirely on renewable solar energy to drive hydrogen production. To date, existing STCH designs have limited efficiency, with only about 7% of incoming sunlight used to make hydrogen and the results low-yield and high-cost, according to the MIT team.

However, in contrast, the engineers estimate the new design could harness up to 40% of the sun’s heat to generate that much more hydrogen. ‘The increase in efficiency could drive down the system’s overall cost, making STCH a potentially scalable, affordable option to help decarbonise the transportation industry’ claims the team.

‘We’re thinking of hydrogen as the fuel of the future, and there’s a need to generate it cheaply and at scale,’ explains the study’s lead author, Ahmed Ghoniem, Professor of Mechanical Engineering at MIT. ‘We’re trying to achieve the [US] Department of Energy’s goal, which is to make green hydrogen by 2030, at $1/kg. To improve the economics, we have to improve the efficiency and make sure most of the solar energy we collect is used in the production of hydrogen.’

Similar to other proposed designs, the MIT system would be paired with an existing source of solar heat, such as a concentrated solar plant (CSP) – a circular array of hundreds of mirrors that collect and reflect sunlight to a central receiving tower. An STCH system then absorbs the receiver’s heat and directs it to split water and produce hydrogen. This process is very different from electrolysis, which uses electricity instead of heat to split water.

At the heart of a conceptual STCH system is a two-step thermochemical reaction. In the first step, water in the form of steam is exposed to a metal. This causes the metal to grab oxygen from steam, leaving hydrogen behind. This metal ‘oxidation’ is similar to the rusting of iron in the presence of water, but it occurs much faster. Once hydrogen is separated, the oxidised (or rusted) metal is reheated in a vacuum, which acts to reverse the rusting process and regenerate the metal. With the oxygen removed, the metal can be cooled and exposed to steam again to produce more hydrogen. This process can be repeated hundreds of times.

The MIT system is designed to optimise this process. The system as a whole resembles a train of box-shaped reactors running on a circular track. In practice, this track would be set around a solar thermal source, such as a CSP tower. Each reactor in the train would house the metal that undergoes the redox, or reversible rusting, process.

Each reactor would first pass through a hot station, where it would be exposed to the sun’s heat at temperatures of up to 1,500°C. This extreme heat would effectively pull oxygen out of a reactor’s metal. That metal would then be in a ‘reduced’ state – ready to grab oxygen from steam. For this to happen, the reactor would move to a cooler station at temperatures around 1,000°C, where it would be exposed to steam to produce hydrogen.

Other similar STCH concepts have run up against a common obstacle – what to do with the heat released by the reduced reactor as it is cooled. Without recovering and reusing this heat, the system’s efficiency is too low to be practical.

A second challenge has to do with creating an energy-efficient vacuum where metal can de-rust. Some prototypes generate a vacuum using mechanical pumps, although the pumps are too energy-intensive and costly for large-scale hydrogen production.

To address these challenges, the MIT design incorporates several energy-saving workarounds. To recover most of the heat that would otherwise escape from the system, reactors on opposite sides of the circular track are allowed to exchange heat through thermal radiation; hot reactors get cooled while cool reactors get heated. This keeps the heat within the system. The researchers also added a second set of reactors that would circle around the first train, moving in the opposite direction. This outer train of reactors would operate at generally cooler temperatures and would be used to evacuate oxygen from the hotter inner train, without the need for energy-consuming mechanical pumps.

These outer reactors would carry a second type of metal that can also easily oxidise. As they circle around, the outer reactors would absorb oxygen from the inner reactors, effectively de-rusting the original metal, without having to use energy-intensive vacuum pumps. Both reactor trains would run continuously and would generate separate streams of pure hydrogen and oxygen.

The researchers carried out detailed simulations of the conceptual design and found that it would significantly boost the efficiency of solar thermochemical hydrogen production, from 7%, as previous designs have demonstrated, to 40%.

The team intend to build a prototype of the system in 2024 that will be tested in CSP facilities at laboratories of the US Department of Energy, which is currently funding the project.

‘When fully implemented, this system would be housed in a little building in the middle of a solar field,’ explains co-author Aniket Patankar. ‘Inside the building, there could be one or more trains each having about 50 reactors. And we think this could be a modular system, where you can add reactors to a conveyor belt, to scale up hydrogen production.’
